GENERATOR SET SPECIFICATIONS
Standby Power (kVA) | 2500 |
Standby Power (kW) | 2000 |
Prime Power (kVA) | 2250 |
Prime Power (kW) | 1800 |
Power Factor (Cos Phi) | 0.8 |
Diesel Engine Model | 16V4000G63F |
Frequency (Hz) | 50 |
Rated Speed (rpm) | 1500 |
Phase | 3 |
Standrad Voltage (V) | 400/230 |
Available Voltage (V) | 380/220 415/240 |
GENERATOR SET DIMENSIONS
Type | Open Set Silent Set |
Length - Maximum | 6100 40HQ Container |
Width - Maximum | 2200 / |
Height - Maximum | 2800 / |
ENGINE SPECIFICATIONS
Engine model | 16V4000G63F |
Engine type | 4 stroke diesel |
Governor type | Electric |
Injection type | Direct |
Aspiration type | Turbocharger and intercooler |
Number of cylinders and arrangement | 16-V |
Bore and stroke (mm*mm) | 170*210 |
Displacement (L) | 76.3 |
Cooling system | water-cooled |
Fuel consumption @75% load (g/kWh) | 191 |
ALTERNATOR SPECIFICATIONS
Number of phase | 3 |
Poles | 4 |
Winding Connections (standard) | Star-series |
Insulation | H class |
Enclosure (accordingly to IEC-34-5) | IP23 |
Excitation system | Self-excited, brushless |
Voltage regulator | AVR |
