GENERATOR SET SPECIFICATIONS
Standby Power (kVA) | 27.5 |
Standby Power (kW) | 22 |
Prime Power (kVA) | 25 |
Prime Power (kW) | 20 |
Power Factor (Cos Phi) | 0.8 |
Diesel Engine Model | Y495D |
Frequency (Hz) | 50 (60) |
Rated Speed (rpm) | 1500 (1800) |
Phase | 3 |
Standrad Voltage (V) | 400/230 (220/127) |
Available Voltage (V) | 380/220 415/240 (440/254) |
GENERATOR SET DIMENSIONS
Type | Open Set Silent Set |
Length - Maximum | 1870 2250 |
Width - Maximum | 730 850 |
Height - Maximum | 1250 1140 |
ENGINE SPECIFICATIONS
Engine model | Y495D |
Engine type | 4 stroke diesel |
Governor type | Electric |
Injection type | Direct |
Aspiration type | Natural Aspiration |
Number of cylinders and arrangement | 4-L |
Bore and stroke (mm*mm) | 95*105 |
Displacement (L) | 2.997 |
Cooling system | water-cooled |
Fuel consumption @75% load (g/kW.h) | ≤240 |
ALTERNATOR SPECIFICATIONS
Number of phase | 3 |
Poles | 4 |
Winding Connections (standard) | Star-series |
Insulation | H class |
Enclosure (accordingly to IEC-34-5) | IP23 |
Excitation system | Self-excited, brushless |
Voltage regulator | AVR |
