GENERATOR SPECIFICATIONS
Model | FDW300E |
Alternator type | Brush, 2-pole, Welding |
Voltage (V) | 110-240 |
Frequency (Hz) | 50/60 |
Rate. AC Output (kW) | 3.0/3.3 |
Max. AC Output (kW) | 3.3/3.6 |
Power Factor | 1.0 |
DC Output (V/A) | 12/6 |
Fuel consumption (kW.h) | ≤350 |
Noise level at 7 meter, dB(A) | ≤82 |
Engine Model | FA290F |
Engine Type | Twin-cylinder, Vertical, 4-stroke, air-cooled, direction injection |
Displacement (cc) | 954 |
Engine Speed (rpm) | 3000/3600 |
Starting Method | Electric |
Lube Oil Capacity (L) | 3 |
Fuel Capacity (L) | 25 |
Dimension (L*W*H) mm | 1070*578*668 |
Net Weight (kg) | 195 |
WELDER SPECIFICATIONS
No load Voltage (V) | 75~80 |
Operating welding voltage (V) | 22~32 |
Operation Current (A) | 50~250 |
Max. Arcing Current (A) | 300 |
Duty Cycle (a) | 60% |
